Concept
Professional LED projector.
Material
Die-cast painted aluminium optical unit.
Power supply box made of painted ABS.
The optical unit can be adjusted from 0 to -90° on the vertical plane; and 360° on the horizontal plane with aiming blocking system.
Source
High efficiency Ra97 LED Chip on Board.
Ra90 on request.
Optic
Different optical systems depending on beam angles: NSP version with an indirect optic with a LED module directed towards the reflector, heat-pipe dissipation, a highly reflective anodised aluminium parabolic reflector and a transparent PMMA refractive screen.
SP and FL versions with a hybrid optic composed of an anodised mirrored aluminium reflector, an optical glass lens, a black anodised aluminium lens holder and a PMMA holographic filter.
MWFL and WFL versions with convex faceted highly reflective anodised aluminium precision optics and a PMMA holographic filter.
WW version with an highly reflective mirrored pre-anodised aluminium optic, a PMMA holographic filter and a painted plastic black screen.
Installation
Mechanical and optic accessories available, to be installed with holder ring (necessary).
Power Supply
Integrated power supply available for the electronic, DALI and Casambi versions and 1-10V with a dimmer on board.
Notes
110-277Vac version available on request.
