Projectors

Jedi Nova 55 Projector Comfort 1200

Code

E0534GFL840ELBA

Light colour
4000K
80
Light distribution
Grazing
10° / 37°
Output
70W
6239lm
Power supply
Control
220-240Vac
ON-OFF
Colour
Color
4.7
IP66
IP67
IP68
IK07
ItemMainImage
ItemMainImage
ItemMainImage
ItemSmallImage
ItemSmallImage
ItemSmallImage
1 / 3
Prev
Next

Technical Data

Concept
Adjustable linear LED projector.
Source
High Power High Efficiency Ra80 linear LED board.
Energy efficiency class
Nominal power63
Nominal flux9596lm
Colour rendering index80
CCT nominal4000K
Lifetime (L80/B10)100000h tq +25°C
Lifetime (L90/B10)96000h tq +25°C
Illuminotechnical characteristics
Optic made of optical grade PMMA TIR lenses and a holographic filter. Comfort version with integrated optical accessory: longitudinal anti-glare screen in black painted steel.
OpticGrazing
Beam anglesGRZ 10°x40°
Optical efficiency65.02%
Fixture flux6239lm
Luminous efficacy89lm/W
Photobiological safetyCompliant with RG1 low risk group
Mechanical characteristics
Extruded anodised aluminium 15µ body. Extra clear 5mm thick glass flat screen. The body of the fixture is adjustable and can be installed away from the mounting surface using accessory snap brackets.
Colour and finishBlack anodized
DimensionsAxBxH 1148x55x90mm
Weight4.7Kg
VersionComfort
Degree of protectionIP66,IP67,IP68
Mechanical ResistanceIK07
Electrical characteristics
Integrated driver, available in the ON-OFF version (positioned below the optical body). Supplied with through-wiring withlongitudinal sealing IN/OUT panel connectors (the sealing limits the risk of humidity raising towards the driver/optical body). Luminaire compliant with EN 60598-2-22 for power supply from a centralised emergency system CPSS (Central Power Supply System), not incorporated in the luminaire - high risk areas excluded. The default power and flux are 100% in AC and 100% in DC.
Fixture Power70W
Power supply220-240Vac 50/60Hz
Insulation ClassCLASS 1
Type of driver / ControlON-OFF
Driver includedYES
SAFE FLICKERPstLM=<1 and SVM=<0.4 (IEC TR 61547-1 and IEC TR 63158), to ensure a more comfortable and safe light
Ambient temperature-25°C / +35°C
Installation
To be completed with powder coated stainless steel fixed or adjustable brackets (available in different lengths).
Notes
110-277Vac version available on request.
Warranty
5 years.
Warning
Luminaire designed for disposal/recycling at end-of-life. Replaceable (LED only) light source by a professional. Replaceable control gear by a professional.

Related codes

AccessoryImage
AccessoryImage FullScreenIcon
DesignModalImage
1 / 2
Prev
Next
CodeColour
A108BTColor
Fixed bracket kit in powder-coatedstainless steel for surface installation (2 pieces).
AccessoryImage
AccessoryImage FullScreenIcon
DesignModalImage
1 / 2
Prev
Next
CodeColourVersionL
A109BTColorShort57mm
Adjustable bracket kit in powder-coated stainless steel for surface installation (2 pieces). Rotation +/-90°.
AccessoryImage
AccessoryImage FullScreenIcon
DesignModalImage
1 / 2
Prev
Next
CodeColourVersionL
A110BTColorMedium157mm
Adjustable bracket kit in powder-coated stainless steel for surface installation (2 pieces). Rotation +/-90°.
AccessoryImage
AccessoryImage FullScreenIcon
DesignModalImage
1 / 2
Prev
Next
CodeColourVersionL
A111ZBTColorLong303mm
A111YBTColorLong453mm
A111XBTColorLong603mm
Adjustable bracket kit in powder-coated stainless steel for surface installation (2 pieces). Rotation +/-90°.
AccessoryImage
AccessoryImage FullScreenIcon
DesignModalImage
1 / 2
Prev
Next
CodeColourH
A112Color181mm
Earthspike. Powder coated stainless steel. To be used with A108, A109, A110.

Accessories

AccessoryFoto
Code
A117
IP66/IP68 female connector. 5 pôles (STANDARD 3G2,5mm² MAX, DALI 5G1,5mm² MAX). Cable diameter range from 7 to 12mm.
AccessoryFoto
Code
A118
Male/female IP66/IP68 connector kit. 5 pôles (STANDARD 3G2,5mm² MAX, DALI 5G1,5mm² MAX). Cable diameter range from 7 to 12mm.
AccessoryFoto
Code
A119
Multiple connection box IP68. 1 IN - 2 OUT 5 poles (STANDARD 3G2,5mm² MAX, DALI 5G1,5mm² MAX). Cable diameter range from 7 to 12mm.
AccessoryFoto
CodeL
A120Z1000mm
A120Y2000mm
A120X3000mm
Connection cable. Complete with 5 pole connectors. For the ON-OFF and DALI version.
AccessoryFoto
CodeColourL
A148ZBAColor1148mm
Paraluce estetico e antiabbagliamento in alluminio verniciato. Versione per proiettore standard e side box.
AccessoryFoto
CodeColourL
A156ZBAColor1148mm
Paraluce estetico e antiabbagliamento in alluminio verniciato. Versione per proiettore standard.

Downloads

Jedi Nova 55 Projector Comfort 1200ItemImage
Jedi Nova 55 Projector Comfort 1200
