Wall mounted luminaires
Zeno 130 Applique
Code
T040WWR940ELDB
Light colour
4000K
90
90
Light distribution
Wall Washer
Output
29.5W
1869lm
1869lm
Power supply
Control
220-240Vac
ON-OFF
ON-OFF
Colour
1 / 3
Technical Data
Source
High efficiency Chip on Board LED Ra90. Ra97 on request.
Energy efficiency classE
Nominal power26W
Nominal flux3302lm
Colour rendering index90
Rf90
Rg98
CCT nominal4000K
SDCM2
Lifetime (L80/B10)>50000h tq +25°C
Illuminotechnical characteristics
A highly reflective specular pre-anodised aluminium Wall Washer optical system, a holographic PMMA screen and a black polymer covering element.
OpticWALL WASHER
Beam anglesWW
Optical efficiency57%
Fixture flux1869lm
Luminous efficacy63lm/W
Photobiological safetyCompliant with RG1 low risk group
Mechanical characteristics
Die-cast painted aluminium optical unit and power supply box. The optical unit can be adjusted from 0 to -90° on the vertical plane; and 355° on the horizontal plane with aiming blocking system.
Colour and finishDeep black
Weight0.85Kg
Degree of protectionIP40
Electrical characteristics
Integrated electronic power supply.
Fixture Power30W
Power supply220-240Vac 50/60Hz
Insulation ClassCLASS 1
Type of driver / ControlON-OFF
Driver includedYES
Class FYES
SAFE FLICKERPstLM=<1 and SVM=<0.4 (IEC TR 61547-1 and IEC TR 63158), to ensure a more comfortable and safe light
Ambient temperature0°C / +25°C
Installation
Steel plate for wall installation.
Notes
110-277Vac version available on request.
Warranty
5 years.
Accessories
Downloads
